FL Series LED Flood Light - Field Selectable

FL-300 Selectable LED Flood Light

FL-300 Selectable LED Flood Light

Field-selectable single-head LED flood light with 300W power-adjustable driver. Features four power and three CCT settings that can be set at install. Includes yoke mount bracket.

  • 13,500 - 45,000 lumens
  • 300W power-selectable
  • 3000K, 4000K & 5000K CCT
  • 65°x95° or 35°x85°
  • 120-277V or 277-480V

CONFIGURE & REQUEST QUOTE

Select your options & add ons, then click Add to Quote. You can add multiple products or configurations before submitting your quote request.

Beam Angle
Voltage
Finish

Quick Ship | SKU:

Return to main product:
FL Series LED Flood Light - Field Selectable View full details

DETAILS

This model features a 300W driver with 100%, 75%, 50%, and 30% power settings, plus 3000K/4000K/5000K CCT selections. Available with 65° x 95° or 35° x 85° beam angle and in black or bronze finish. For DLC information, email sales@ledlivingtechnology.com.

DOWNLOADS

Download Spec Sheet LLTVFL Series Flood Lights PDF Datasheet

DLC SPECIFICATIONS

LLTVFL-300WCS
DLC Specifications

Configuration
65x95 degrees
100-277V
Black
DLC Classification
Premium
DLC Lumens
40200 lm
DLC Wattage
300.0 Watts
Luminous Efficacy
134 lm/W
DLC CCT
3000K
DLC CRI
70
DLC Integral Controls
No
DLC Primary Use
Outdoor Pole/Arm-Mounted Area and Roadway Luminaires

LLTVFL-300WCS-BZ
DLC Specifications

Configuration
65x95 degrees
100-277V
Bronze
DLC Classification
Premium
DLC Lumens
40200 lm
DLC Wattage
300.0 Watts
Luminous Efficacy
134 lm/W
DLC CCT
3000K
DLC CRI
70
DLC Integral Controls
No
DLC Primary Use
Outdoor Pole/Arm-Mounted Area and Roadway Luminaires

LLTVFL-300WCS-FN
DLC Specifications

Configuration
35x85 degrees
100-277V
Black
DLC Classification
Premium
DLC Lumens
39900 lm
DLC Wattage
300.0 Watts
Luminous Efficacy
133 lm/W
DLC CCT
3000K
DLC CRI
70
DLC Integral Controls
No
DLC Primary Use
Outdoor Pole/Arm-Mounted Area and Roadway Luminaires

LLTVFL-300WCS-FN-BZ
DLC Specifications

Configuration
35x85 degrees
100-277V
Bronze
DLC Classification
Premium
DLC Lumens
39900 lm
DLC Wattage
300.0 Watts
Luminous Efficacy
133 lm/W
DLC CCT
3000K
DLC CRI
70
DLC Integral Controls
No
DLC Primary Use
Outdoor Pole/Arm-Mounted Area and Roadway Luminaires

ACCESSORIES

Mounting Options: The light comes with a yoke mount bracket installed. Available as accessories are 60mm or 76mm sleeve adjustable-angle slipfitter mounts for pole mounting and an adjustable wall mount bracket.

NEMA Socket: ANSI C136.41-2013 Dimming Receptacle, 3pin

Photocell: Factory installed: must be specified at time of order. Compatible with yoke mount bracket only.

Return to main product: FL Series LED Flood Light - Field Selectable
